MEYLE Stepping Motors

Stepping motors with high torque at low speeds in different sizes and power ranges with high step angle accuracy. Electronically commutated (EC) brushless DC motors for machine applications.Stepping motors with high torque at low speeds in different sizes and power ranges with high step angle accuracy. Electronically commutated (EC) brushless DC motors for machine applications.

• Digital controlled positioning and speed control operating without position feedback
• Diameter of 20 - 86 mm
• up to IP 68 protection
• Stepping angles of 0,9 - 1,8° / 120°
• High torque and high step angle accuracy
• Spindle stepping motors from 0,003 - 0,04 mm / step
• Digital controler for stepping and spindle stepping motors
• System integration with application engineers more than 40 years martket experience
• ISO 9001:2008 certified since 1998

1. Size: Motor outside diameter in tenths of an inch (Motor Dimensions)
2. Type of Stepping Motor: "H" mean Hybrid Stepping Motor
3. Type of Step Angle:
   S: Step angle 1.8°, stator with 8 polar
   C: Step angle 0.9°, stator with 8 polar
   T: Step angle 1.2°
   Y: Step angle 0.6
   F: Step angle 0.72°
4. Length of stator core
5. Type of lead wires:
   "0" indicates connector only
   "4, 5, 6, 8" indicates number of lead wires
6. Electric variation: variety of current, torque, etc
7. Mechanical variation: variety of shaft, lead wires, screws, etc.

HB-20S, HB-28S, HB-42S, HB-42C, HB-57S, HB-57FS, HB-60S, HB-86S, HB-60T, HB-86T, 36 BLDC, 42Y BLDC, 42 BLDC, 57 BLDC, 90 BLDC
